| Liner Part Number Crossovers | ||||||
| EMSCO FB-1300 / 1600 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-2145-54HP | 5.1/2″ Liner, Steel, FB1300/FB1600 | 05499550HP | 6390G3 | 051616000 | ||
| AC-2145-60HP | 6″ Liner, Steel, FB1300/FB1600 | 05499600HP | 6390G5 | 051616200 | ||
| AC-2145-64HP | 6.1/2″ Liner, Steel, FB1300/FB1600 | 05499650HP | 6390G7 | 051616300 | ||
| AZ-07499550 | 5.1/2″ Liner, Zirconia, FB1300/FB1600 | 07499550 | 6390ZIR3 | |||
| AZ-07499600 | 6″ Liner, Zirconia, FB1300/FB1600 | 07499600 | 3690ZIR5 | |||
| AZ-07499650 | 6.1/2″ Liner, Zirconia, FB1300/FB1600 | 07499650 | 6390ZIR7 | |||
| EMSCO FC-2200 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-2200-54HP | 5.1/2″ Liner, Steel, FC2200 | 05551550HP | 6394G3 | 052126400 | ||
| AC-2200-60HP | 6″ Liner, Steel, FC2200 | 05551600HP | 6394G5 | 052126500 | ||
| AC-2200-64HP | 6.1/2″ Liner, Steel, FC2200 | 05551650HP | 6394G7 | 052126600 | ||
| AZ-07551550 | 5.1/2″ Liner, Zirconia, FC2200 | 07551550 | 6394ZIR3 | |||
| AZ-07551600 | 6″ Liner, Zirconia, FC2200 | 07551600 | 6394ZIR5 | |||
| AZ-07551650 | 6.1/2″ Liner, Zirconia, FC2200 | 07551650 | 6394ZIR7 | |||
| GARDNER DENVER PZ-10 / 11 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-0197-54HPL | 5.1/2″ Liner, Steel, PZ10/PZ11 | 05496550HP | 1377G3 | 051473100 | ||
| AC-0197-60HPL | 6″ Liner, Steel, PZ10/PZ11 | 05496600HP | 1377G5 | 051473200 | ||
| AC-0197-64HPL | 6.1/2″ Liner, Steel, PZ10/PZ11 | 05496650HP | 1377G7 | 051473500 | ||
| AZ-07496550 | 5.1/2″ Liner, Zirconia, PZ10/PZ11 | 07496550 | 1377ZIR3 | |||
| AZ-07496600 | 6″ Liner, Zirconia, PZ10/PZ11 | 07496600 | 1377ZIR5 | |||
| AZ-07496650 | 6.1/2″ Liner, Zirconia, PZ10/PZ11 | 07496650 | 1377ZIR7 | |||
| Liner Part Number Crossovers | ||||||
| NATIONAL 12P160 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-0259-54HP | 5.1/2″ Liner, Steel, 12P160 | 05466550HP | 1376G3 | 051429100 | ||
| AC-0259-60HP | 6″ Liner, Steel, 12P160 | 05466600HP | 1376G5 | 051429300 | ||
| AC-0259-64HP | 6.1/2″ Liner, Steel, 12P160 | 05466650HP | 1376G7 | 051429500 | ||
| AZ-07466550 | 5.1/2″ Liner, Zirconia, 12P160 | 07466550 | 1376ZIR3 | |||
| AZ-07466600 | 6″ Liner, Zirconia, 12P160 | 07466600 | 1376ZIR5 | |||
| AZ-07466650 | 6.1/2″ Liner, Zirconia, 12P160 | 07466650 | 1376ZIR7 | |||
| NATIONAL 14P200 / 14P220 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-0260-54HP | 5.1/2″ Liner, Steel, 14P220 | 05545550HP | 6382G3 | 052126800 | ||
| AC-0260-60HP | 6″ Liner, Steel, 14P220 | 05545600HP | 6382G5 | 052126900 | ||
| AC-0260-64HP | 6.1/2″ Liner, Steel, 14P200 | 05545650HP | 6382G7 | 052127000 | ||
| AZ-07545550 | 5.1/2″ Liner, Zirconia, 14P220 | 07545550 | 6382ZIR3 | |||
| AZ-07545600 | 6″ Liner, Zirconia, 14P220 | 07545600 | 6382ZIR5 | |||
| AZ-07545650 | 6.1/2″ Liner, Zirconia, 14P220 | 07545650 | 6382ZIR7 | |||
| Liner Part Number Crossovers | ||||||
| OILWELL A-1400 / 1700-PT | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-0284-54HP | 5.1/2″ Liner, Steel, A1400TP/A1700PT | 05326551HP | 1388G3 | 051544600 | ||
| AC-0284-60HP | 6″ Liner, Steel, A1400PT/A1700PT | 05326601HP | 1388G5 | 051544800 | ||
| AC-0284-64HP | 6.1/2″ Liner, Steel, A1400PT/A1700PT | 05326651HP | 1388G7 | 051545000 | ||
| AZ-07326550 | 5.1/2″ Liner, Zirconia, A1400PT/A1700PT | 07326550 | 1388ZIR3 | |||
| AZ-07326600 | 6″ Liner, Zirconia, A1400PT/A1700PT | 07326600 | 1388ZIR5 | |||
| AZ-07326650 | 6.1/2″ Liner, Zirconia, A1400PT/A1700PT | 07326650 | 1388ZIR7 | |||
| WIRTH TPK-2200 | ||||||
| Acumen PartNumber |
EXTENDED DESCRIPTION | Cross References NOV |
Cross References SWOP |
Cross References Forum |
||
| AC-5576-54HP | 5.1/2″ Liner, Steel, WIRTH TPK2200 | 05557550HP | 6380G3 | |||
| AC-5576-60HP | 6″ Liner, Steel, WIRTH TPK2200 | 05557600HP | 6380G5 | |||
| AC-5576-64HP | 6.1/2″ Liner, Steel, WIRTH TPK2200 | 05557650HP | 6380G7 | |||
| AZ-07557550 | 5.1/2″ Liner, Zirconia, WIRTH TPK2200 | 07557550 | 6380ZIR3 | |||
| AZ-07557600 | 6″ Liner, Zirconia, WIRTH TPK2200 | 07557600 | 6380ZIR5 | |||
| AZ-07557650 | 6.1/2″ Liner, Zirconia, WIRTH TPK 2200 | 07557650 | 6380ZIR7 | |||
| F-1300/1600 Запчасти к буровым насосам | F-1300/1600 Запчасти к буровым насосам | ||||
| Наименование | Старая модель | Новая модель | Наименование | Старая модель | Новая модель |
| F1300/F1600 | F-1300/F1600 | F1300/F1600 | F-1300/F1600 | ||
| Корпус в сборе | AH36002-01.00 | AH1301020100 | Корпус в сборе | AH36002-01.00 | AH1301020100 |
| Коленчатый сборки | AH36002-02.00 | AH1301020200 | Коленчатый сборки | AH36002-02.00 | AH1301020200 |
| AH37002-01.00 | AH1601020100 | AH37002-01.00 | AH1601020100 | ||
| Шестерня вал в сборе | AH36002-03.00 | AH1301020300 | Шестерня вал в сборе | AH36002-03.00 | AH1301020300 |
| AH37002-02.00 | AH1601020200 | AH37002-02.00 | AH1601020200 | ||
| Ползун Головной блок | AH36002-04.00 | AH1301020400 | Ползун Головной блок | AH36002-04.00 | AH1301020400 |
| Гидравлический конец сборки | AH36002-05.00 | AH1301020500 | Гидравлический конец сборки | AH36002-05.00 | AH1301020500 |
| Смазаны Силовой блок в сборе | AH36002-06A.00 | AH1301020600 | Смазаны Силовой блок в сборе | AH36002-06A.00 | AH1301020600 |
| Основание седла | AH36002-07.00 | AH1301020700 | Основание седла | AH36002-07.00 | AH1301020700 |
| Распылительный насос в сборе | AH36002-08.00 | AH1301020800 | Распылительный насос в сборе | AH36002-08.00 | AH1301020800 |
| BS Имя плиты | AH13010209 | AH13010209 | BS Имя плиты | AH13010209 | AH13010209 |
| AH37002-03B | AH16010203 | AH37002-03B | AH16010203 | ||
| Любые инструменты | AH36002-10.00 | AH1301021000 | Любые инструменты | AH36002-10.00 | AH1301021000 |
| Любые запасные части | AH36002-11.00 | AH1301021100 | Любые запасные части | AH36002-11.00 | AH1301021100 |
| Узел разгрузки фильтра | AH34004-18.00 | AH1001021100 | Узел разгрузки фильтра | AH34004-18.00 | AH1001021100 |
| Шайба упротнения | AH33001-09 | AH10010109 | Шайба упротнения | AH33001-09 | AH10010109 |
| Вентиляционная крышка | T515-1001.00 | T515-1001.00 | Вентиляционная крышка | T515-1001.00 | T515-1001.00 |
| Кран | AH36001-10.00 | AH1301011000 | Кран | AH36001-10.00 | AH1301011000 |
| Кран | AH36001-11A.00 | AH1301011100 | Кран | AH36001-11A.00 | AH1301011100 |
| Крышка | AH36001-12.00 | AH1301011200 | Крышка | AH36001-12.00 | AH1301011200 |
| Шайба упротнения | AH36001-13 | AH13010113 | Шайба упротнения | AH36001-13 | AH13010113 |
| Индикаторная | AH33001-17B | AH10010113 | Индикаторная | AH33001-17B | AH10010113 |
| AH33001-17A | AH10010210 | AH33001-17A | AH10010210 | ||
| Масломер в сборе | AH33001-18.00 | AH1001011400 | Масломер в сборе | AH33001-18.00 | AH1001011400 |
| Крышка экскреции(III) | AH33001-22.00 | AH1001011500 | Крышка экскреции(III) | AH33001-22.00 | AH1001011500 |
